Twistloc® 12mm Tube x 1/2" BSP Female Adaptor SPSU6734BM WaterMark Certified (10-102WM)

In stock
Quick Overview
  • Simple and Easy to install.
  • Secure connection indicator helps confirm leak-free joints.
  • Easy verification of coupling (lock/unlock) status, even from a distance.
  • Removable and reusable without damage to plumbing or fittings.
  • Lightweight for easy handling.
  • Strong connection suitable for heating systems.
  • Product traceability - code printed on the product to track manufacturing quality control.
  • Flame-free, no need for a blowtorch.
  • No corrosion or mineral build-up.
  • Low heat diffusion ensures safe surface temperature.
  • More resistant to bursting under freezing temperatures.
  • No lead, non-toxic.
- +


Twistloc® push-in fittings incorporate advanced technology, providing enhanced reliability and effectiveness in comparison to conventional fittings and valves. These innovative fittings guarantee long-lasting performance, granting you peace of mind during installation. By employing visual color connections, all plastic fittings and valves ensure secure connections. Twistloc® products carry certifications for PEX, PB, Copper, and cPVC pipe, enabling effortless combination of different pipe types for repairs or new installations. With straightforward installation procedures, our products significantly reduce labor time, thereby facilitating efficient workflow.

Twistloc® Features

Twistloc® products introduce a convenient and reliable push-fit plumbing system that combines pushfit and twist locking technologies. This unique design ensures a secure and leak-free joint, offering complete peace of mind. Suitable for plumbing, local/home hot water supply, and heating systems, Twistloc® utilizes a pressure and combination system, making it an ideal twist and lock solution. Our products have undergone rigorous testing and received approvals from WRAS, Kitemarked to BS 7291 Parts 1, 2, and 3 Class S, cUPC, NSF, Watermarked to AS 4176.3, and ACS. Manufactured to ISO 9001 BSI standard, they comply with the requirements of central local/home heating and water supply systems. Extensive tests have demonstrated the exceptional resistance of Twistloc® products to temperature and pressure beyond normal operational ranges. The patented secure connection indicator ensures peace of mind by visibly confirming proper joint connection—once the green band is no longer visible, you can be certain of a secure joint. This indicator simplifies installations, enhancing both safety and ease of use. To ensure proper installation, it is crucial to adhere to the correct plumbing regulations. For detailed fitting instructions, please refer to our installation guide.

Usage and Installation

Prepare the Pipe:

Ensure the pipe end is free from score marks. Cut the pipe square using a tube cutting device. To prevent damage to the fitting, remove and burs from the end of the tubing/pipe. When using tube inserts, a twisting motion will aid the insertion.

To Lock the Pipe Connection:

These instructions relate to the installation of  fittings for copper, PB, PEX and cPVC pipes.
Please note that it is the installer’s responsibility to ensure that  fittings, pipework and other components are appropriate for the intended applications, and that products are installed in accordance with the installation instructions and local plumbing codes.
No information in this publication is intended to create any warranty beyond the SNC product warranty applicable to the plumbing system.

Installing push-fit products:
Before you start, inspect the pipe. Ensure there are no scratches, gouges or any form of damage or deformation on the pipe. It should also be free from dirt and grease that may affect the seal.

Pay close attention to the first inch (25.4mm) from the cut ends. Damage or foreign substances in this area may cause leakage problems. If there are any concerns, cut the affected pipe end to a clean and undamaged point.

Don’t use any coarse materials to clean the outside surface of either plastic or copper pipes as this could affect the seal and result in leakage.

Ensure fittings and pipes are always kept clean by keeping them in the packaging provided - don’t empty products onto the floor.

Never insert your finger into the fitting as you risk being cut by the metal ‘grip teeth’ inside the fitting.

To Disconnect:

Make sure that the system is de-pressurised. Unlock fitting by twisting until coloured ring is visible. Press collect squarely against the face of the fitting. With the collet depressed, pull on the pipe to remove it from the fitting.


Do not apply any impact force to  fittings.
 fittings are plastic materials and should not be treated the same as metals.
 fittings may melt, crack or distort if exposed to open flames or excessive heat.
Do not use pipe sealant, thread sealants or Teflon® paste in order to seal threaded fittings. All the connections to  fittings are either a mechanical compression type, or seal with a rubber gasket and do not require any other forms of sealant. Do not insert fingers into  fittings as the stainless steel teeth may cause injury.

If PEX pipe is used, then a tube support liner must be used also. The tube support liner acts as an internal support for the end of the pipe.

 fittings should not be used for gas, fuel oil or compressed air applications.
DO NOT allow contact with any chemical or foreign substance; paint stripers, solder flux, Acid based descalents or chemical.

 fittings are not suitable for buried installation.
All  fittings and related products should be selected, installed, used and maintained in accordance with these Technical Specifications.

When cutting pipe, ensure that the ends are cut square and are free of burrs.

Ensure that there are no scratches, gouges or any form of damage on the circumference of the pipe within 1 in. (25.4mm) of the cut end. Damage in this area may cause leakage. Check the fitting for any signs of damage or foreign objects.

Do not use a damaged or scored pipe.

  • Do not leave burrs on the pipe.
  • Ensure that the pipe is pushed into the fitting fully and is engaged properly in accordance with the instructions.

* If the pipe is not fully inserted, the connection cannot be properly sealed even if the fitting is coupled.
* If these installation guidelines conflict or are inconsistent with local building or plumbing codes, any codes applicable to parallel plumbing systems shall prevail.

Do not use a hacksaw to cut a pipe. Do not leave burrs on the pipe.

Ensure that the pipe is pushed into the fitting fully and is engaged properly in accordance with  instructions.

If the pipe is not fully inserted, the connection cannot be properly sealed even the fitting is coupled.

You must push in the pipe passing the collets (gripper) and the O-ring inside the fitting.

When a connection has to be disassembled and reused, ensure the pipe has no damage around the circumference within 1" (25.4mm) of the end. Inspect the tube and fitting for any signs of damage and ensure they are free of foreign materials. The connection can then be reassembled.

For plastic pipes:
  • Always use an appropriate pipe cutting tool such as plastic pipe shears to cut plastic pipes. Never use a hacksaw as this could cause damage.
For copper pipes:
  • Use a pipe cutting wheel or pipe slice.


Fittings & Valves Performance
Working Temperatures and Pressures
NO. Usual Temp Max Temp Pressures
Cold Water 20˚C 20˚C 12 bar
Hot Water 65˚C 95˚C 6 bar
Central Heating 82˚C * 114˚C 3 bar


Maximum Torque Figures

The Maximum torque values for threads used on  products are as follows

Thread Size Maximum torque
Plastic 1/2″ 3.5Nm
3/4″ 4Nm
1″ 5Nm
